Synology RackStation RS422+ 4-Bay 1U NAS Enclosure (RS422+)

Hardware Specifications
CPU
CPU Model
AMD Ryzen R1600

CPU Quantity
1

CPU Core
2

CPU Architecture
64-bit

CPU Frequency
2.6 (base) / 3.1 (turbo) GHz

Hardware Encryption Engine
Yes

Memory
System Memory
2 GB DDR4 ECC

Storage
Drive Bays
4

Compatible Drive Type
3.5" SATA HDD
2.5" SATA SSD

Hot Swappable Drive
Yes

External Ports
RJ-45 1GbE LAN Port
2

USB 3.2 Gen 1 Port
1
Notes
This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe
PCIe Expansion
1 x Gen3 x2 network upgrade slot

Appearance
Form Factor (RU)
1U

Size (Height x Width x Depth)
44 mm x 478 mm x 327.5 mm

Weight
4.38 kg

Rack Installation Support
4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)
2-post 19" rack (direct mounting)
Notes The rail kit is sold separately

Others
System Fan
40 mm x 40 mm x 3 pcs

Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode

Power Recovery
Yes

Noise Level
28.5 dB(A)

Scheduled Power On / Off
Yes

Wake on LAN / WAN
Yes

Power Supply Unit / Adapter
100 watts

AC Input Power Voltage
100V to 240V AC

Power Frequency
50/60 Hz, Single Phase

Power Consumption
37.93 watts (Access)
13.43 watts (HDD Hibernation)

British Thermal Unit
129.42 BTU/hr (Access)
45.83 BTU/hr (HDD Hibernation)

Temperature
Operating Temperature
0°C to 35°C (32°F to 95°F)

Storage Temperature
-20°C to 60°C (-5°F to 140°F)

Relative Humidity
5% to 95% RH

Certification
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
BIS

Warranty
3-year hardware warranty

Environment
RoHS Compliant

Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
Quick Installation Guide X 1
